TRANSMISSION STANDARDS |
|
|
DVB-S2/S, MPEG-2,MPEG-4,H.264 |
|
|
SATELLITE INPUT/DEMODULATION |
|
|
Connector Type |
F Type |
|
Input Frequency |
950 to 2150 MHz |
|
Signal Input Level |
- 65 to -25 dBm |
|
Band Switch Control |
22KHz |
|
LNB Supply |
13V/18V, IMax 400mA |
|
Demodulation Type |
QPSK,8PSK |
|
Symbol Rate |
2 |
|
LCD FEATURES |
|
|
LCD Type |
TFT Transmissive |
|
Number of Dots |
480(RGB) x272 |
|
Active area (WxH) |
70.02x52.58 mm2 |
|
AV output interface |
|
|
Connector Type |
3.5 mm jack |
|
Video Output |
CVBS |
|
Audio Output |
Stereo Audio L/R output |
|
HDMI output connecter |
|
|
Format |
HDMI 1.3a |
|
AV input interface |
|
|
Connector Type |
3.5 mm jack |
|
Video Input |
CVBS |
|
Audio Input |
Stereo Audio L/R input |
|
AUDIO/VIDEO PROCESSING |
|
|
Video decompression |
MPEG‐2 MP@HL, MPEG‐1Decoding, MPEG‐4 ASP@L5 HD resolution, H.264 MP&HP@L4,HW JPEG decoding |
|
Resolving rate |
PAL‐25 frame@720*576,NTSC‐30frame@720*480 |
|
Signal compatibility |
Support conversion for different video formats |
|
Video Format |
4:3,16:9,By Pan & Scan and Letter Box conversion |
|
Audio Decompression |
MPEG‐1 Layer I/II, MPEG‐2 Layer I/II |
|
Audio Output Mode |
Stereo, Mono,R/L |
|
DATA SERVICE PORT |
|
|
Connector |
USB |
|
Data Protocol |
USB2.0 interface |
|
File Management System |
NTFS,FAT32,FAT16 |
|
File Format |
wma,mp3,mp4,avi,jpg,jpeg,bmp,img |
|
MICROPROCESSOR |
|
|
Microprocessor |
78346 |
|
Clock Frequency |
550MHz |
|
SDRAM Memory |
DDR2 512Mbit |
|
POWER SUPPLY |
|
|
Li‐Ion Battery |
7.4V/3000mAh |
|
Adapter |
OUTPUT :DC12V/1.5A, INTUPT:100‐240VAC 50/60Hz |
|
Power Consumption |
Max. 10W |
|
PHYSICAL CHARACERSTICS |
|
|
Size (W x D x H) |
10.1x17.7 x4.7(cm3) |
|
Net Weight |
0.46kg |
