Electrical Specification |
||
|
Input Frequency |
10.7---12.75GHZ |
||
|
Output Frequency |
950---2150MHZ |
||
|
Local Oscillator Frequency |
Low Band:9.75GHZ |
||
|
High Band:10.6GHZ |
|||
|
Local Oscillator Tolerance |
±1M(max)-40℃--70℃ |
||
|
Convention Gain |
62-65dB |
||
|
Gain Flatness |
±0.5dB/36M |
||
|
Phase Noise |
-60dBc/HZ@1kHZoffset |
||
|
Noise Figure |
0.1dB |
||
|
Cross Polarization |
45dB |
||
|
Model: |
Single |
Output VSWR |
2.0:1(TYP)@25℃ |
|
Description: |
Single |
Operating Voltage |
Vertical:13-14V(DC) |
|
Price:(FOB shenzhen |
Refer to Quotation |
||
|
Payment Terms: |
Refer to Quotation |
DC Current Consumption |
140MA |
|
Packing: |
1pcs/Giftbox,100pcs/CTN |
Operating Temperature |
-40℃~+60℃ |
|
Delivery: |
3-4Weeks |
Storage Temperature |
-55℃~+80℃ |
